LED Curing Systems 20*20mm

LED UV curing systems can be used for UV glue, UV ink, UV varnish, UV paint, UV coating, and other photosensitive materials cure. LED curing systems application areas are wide, suitable for ink printing, industrial products fixed, specific applications can be referred to the following:

1、optical communication industry
active devices, passive device packaging, optical fiber optical cable coating curing bonding;

2、photovoltaic new energy
photovoltaic chips, lithium battery module curing;

3、semiconductor materials
wafer chips, uv film debonding;

4、medical devices
medical catheters, syringes, endoscopes, infusion tubes and other medical devices sealing;

5、3C electronics
mobile phone parts, digital camera accessories, motor components, semiconductor chips, sensors, encoders, etc.;

6、PCB circuit board
electronic components fixed, core circuit potting, chip protection, antioxidant coating protection;

7、optical parts
lens modules, optical lenses, infrared night vision assembly bonding;

8、laboratory materials
polymer chemistry, semiconductor materials light curing;

9、ink printing
screen printing label printing.

1、Multi-channel working mode
Standard with a LED light sources, according to the actual use of the situation, choose 1-4 irradiation heads alone or synchronous work, no need to purchase so many controller, effective cost savings;

2、Low power consumption
LED UV curing systems through the led chip for electrical energy; light energy conversion, less energy loss, low power consumption, can save a lot of electricity consumption each year;

3、Clean and environmental protection without pollution
LED curing systems does not contain mercury metal harmful substances, does not produce ozone when used, belongs to a clean and environmentally friendly energy;

4, Compact size
LED UV curing systems is compact in siza, can be customized shape and irradiation area, suitable for use in different working environments;

5、Long service life
LED UV curing systems emits ultraviolet light source through LED lamp, its life time is more than 20,000h on average, can instantly light up/off led ultraviolet light source, not affected by switch closure;

6、High intensity irradiation
irradiation intensity range from 500mw/cm2 ~ 20,000mw/cm2

7、Remote control/interface
Extra RS232/485 for any serial accessory control/interface
